New 2022 CFMOTO UFORCE 800

Experience the perfect blend of work capability and recreational fun with the 2022 CFMOTO UFORCE 800 EPS LX. Whether for work or pleasure, this versatile utility vehicle delivers powerful performance, exceptional comfort, and class-leading features including a standard 3,500 lb winch and 5-year warranty . Built to tackle tough jobs and trail adventures alike, the UFORCE 800 is ready for whatever comes your way.

Power and Performance

At the heart of the UFORCE 800 lies a liquid-cooled, 800cc V-Twin cylinder, 4-stroke engine featuring SOHC valve configuration with 8 valves . This advanced powerplant delivers:

• Maximum Horsepower: 62 HP @ 6,700 rpm
• Maximum Torque: 63 lb-ft @ 6,000 rpm (72 Nm @ 6,400 rpm)
• Fuel System: Electronic fuel injection with Delphi® brand
• Compression Ratio: 10.3:1
• Cooling: Liquid-cooled for consistent performance
• Starter: Electric
• Fuel Type: Regular gasoline

The engine is mated to an automatic Continuously Variable Transmission (CVT) with Low, High, Neutral, Reverse, and Park (L/H/N/R/P) gearing, featuring the CV-Tech IBC clutch system for smooth power delivery .

Speed and Capability

The UFORCE 800 delivers impressive speed for a utility-focused vehicle:

• Verified top speed: 98 km/h (61 mph)
• Note: The speedometer may read slightly higher than actual GPS-measured speed, and real-world top speed varies based on terrain, passenger/cargo weight, and riding conditions
• Low Range: Governed speed around 25 mph for maximum low-end torque and control in technical terrain
• Acceleration: The UFORCE 800 features amazing low-end power and will consistently beat competitors off the line for the first 30-50 feet, with the ride smoothing out after 15 mph

Drive System and Capability

The UFORCE 800 features a sophisticated drivetrain designed for maximum versatility:

• Drive System: Selectable 2WD / 4WD with shaft drive
• Differential: Locking front differential for maximum traction in challenging conditions
• Driveline Modes: 2 modes (2WD/4WD)
• Power Train: 2WD / 4WD with locking front differential
• Differential Lock Location: Front

Towing and Payload Capacity

The UFORCE 800 delivers impressive work capability:

• Towing Capacity: 1,250 lbs (567 kg)
• Rear Box Capacity: 600 lbs (272 kg) with dumping cargo box
• Rear Hitch: 2-inch receiver type
• Winch: Standard 3,500 lb winch with remote control

Suspension and Ride Quality

The UFORCE 800 features independent suspension all around for a smooth, comfortable ride:

• Front Suspension: Independent Double A-Arm with hydraulic shock absorbers
• Front Travel: 6.3 inches (160 mm)
• Front Adjustable Pre-Load: Yes
• Rear Suspension: Independent Double A-Arm with hydraulic shock absorbers
• Rear Travel: 7.8 inches (200 mm)
• Rear Adjustable Pre-Load: Yes, with 5-position adjustable spring preloading
• Number Rear Shock Absorbers: 2
• Rear Stabilizer Bar: Yes

Steering and Brakes

• Steering: Electric Power Steering (EPS) with steering wheel control
• Steering Type: Power-assisted for effortless maneuverability
• Front Brakes: Dual hydraulic disc
• Rear Brakes: Hydraulic disc
• Brake Actuation: Hydraulic
• Parking Brake: Park in-transmission

Tires and Wheels

• Front Tires: AT 26 x 9-14
• Rear Tires: AT 26 x 11-14
• Tread Type: All Terrain
• Front Wheel Diameter: 14-inch aluminum alloy
• Rear Wheel Diameter: 14-inch aluminum alloy
• Wheels Composition: Aluminum

Dimensions and Capacities

• Overall Length: 117.3 inches (2,980 mm)
• Overall Width: 58.6 inches (1,488 mm)
• Overall Height: 72.8 inches (1,850 mm)
• Wheelbase: 72 inches (1,830 mm)
• Ground Clearance: 10.2 inches (260 mm)
• Seat Height: 17.5 inches (445 mm)
• Vehicle Weight (wet): 1,378 lbs (625 kg)
• Fuel Capacity: 6.86 gallons (26 L)
