Description

2021 Polaris RZR XP Turbo EPS

Experience the instantaneous acceleration of 168 horsepower of turbocharged thrust that puts you in control of extreme performance . The 2021 Polaris RZR XP Turbo EPS is engineered for benchmark performance with power that comes on strong and never falters. This power is paired with highly capable suspension technology in a perfectly balanced chassis for confidence and control that defines the off-road experience .

Power and Performance

At the heart of the RZR XP Turbo EPS lies a liquid-cooled, 925cc ProStar™ 4-Stroke DOHC Twin Cylinder engine featuring electronic fuel injection and a turbocharger . This advanced powerplant delivers:

• Maximum Horsepower: 168 HP at 8,000 rpm
• Maximum Torque: 114 lb-ft
• Displacement: 925 cc
• Bore x Stroke: 93mm x 68mm
• Compression Ratio: 9.0:1
• Cooling: Liquid-cooled for consistent performance
• Fuel System: Electronic fuel injection
• Starter: Electric
• Fuel Type: Regular gasoline
• Alternator Output: 660 W @ 3000 RPM

The engine is mated to an automatic POLARIS Variable Transmission (PVT) with Park, Reverse, Neutral, Low, and High (P/R/N/L/H) gearing . The transmission features high-performance true on-demand AWD/2WD drive system with improved clutch performance for 2021, allowing riders to keep riding for longer .

Speed and Instrumentation

The RZR XP Turbo EPS features a comprehensive instrumentation package that includes:

• 140-mph speedometer
• 10k-rpm tachometer
• Dual-sweep analog dials with 4-inch LCD Rider Information Center
• User-selectable blue/red backlighting and brightness
• Programmable service intervals
• Speedometer, tachometer, odometer, tripmeter, clock, hour meter
• Gear indicator, fuel gauge, coolant temperature, voltmeter
• Service indicator and codes, seat belt reminder light
• DC outlet

The vehicle’s turbocharged power delivers what Polaris describes as “instantaneous acceleration” that puts you in control of extreme performance .

Drive System and Capability

• Drive System: High Performance True On-Demand AWD/2WD – seamlessly switch between 2WD and AWD on the fly
• Engine Braking System (EBS): Not equipped
• Electronic Power Steering (EPS): Standard with Quick Turn Rack for precise, effortless control
• Fuel Capacity: 9.5 gallons (35.9 L) for extended trail riding
• Driveline Brand: On-Demand™
• Number Of Driveline Modes: 2 modes
• Limited Slip Differential Location: Center

Suspension and Chassis

The RZR XP Turbo EPS features premium suspension components for exceptional handling:

Front Suspension:

• Type: Independent double A-arm with stabilizer bar
• Shocks: 2-inch Walker Evans Needle Shocks with 16-position adjustable clickers
• Wheel Travel: 16 inches (40.6 cm)
• Usable Travel: 20 inches (50.8 cm)
• Front Suspension Brand Name: Walker Evans®
• Front Adjustable Fork Pre-Load: Yes

Rear Suspension:

• Type: Independent trailing arms with stabilizer bar
• Shocks: 2.5-inch Walker Evans Needle Shocks with 16-position adjustable clickers
• Wheel Travel: 18 inches (45.7 cm)
• Usable Travel: 20 inches (50.8 cm)
• Rear Suspension Brand Name: Walker Evans®
• Number Rear Shock Absorbers: 2
• Rear Adjustable Shock / Spring Pre-Load: Yes

The suspension action is outstanding, providing 20 inches of usable travel front and rear to soak up the roughest terrain .

Brakes and Tires

• Front/Rear Brakes: 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Calipers, foot-activated
• Parking Brake: Park In-Transmission
• Front Tires: 29 x 9-14; Maxxis® Bighorn radial tires
• Rear Tires: 29 x 11-14; Maxxis® Bighorn radial tires
• Wheels: 14-inch cast aluminum alloy wheels

Dimensions and Capacities

• Overall Length: 119 inches (302.2 cm)
• Overall Width: 64 inches (162.6 cm) – stable stance for confident handling
• Overall Height: 73.75 inches (187.3 cm)
• Wheelbase: 90 inches (228.6 cm)
• Ground Clearance: 14 inches (35.6 cm)
• Estimated Dry Weight: 1,528 lbs (693 kg)
• Gross Vehicle Weight: 2,343 lbs (1,063 kg)
• Payload Capacity: 740 lbs (336 kg) including riders, cargo, and accessories
• Cargo Box Capacity: 300 lbs (136 kg)
• Bed Box Dimensions (L x W x H): 28 x 22 x 7 inches (72.0 x 57.0 x 17.8 cm)
